4-Slot 26kW Antminer Water Cooler (AP-H4)

Space-efficient hydro-cooling system engineered for residential Bitcoin mining.
An all-in-one cabinet using deionized water for effective heat management while
maintaining operational safety. Plug-and-play design suitable for confined spaces
without compromising cooling performance.

Specifications

• Heat dissipation: 26 kW
• Miner capacity: 4× Antminer S19 / S21 / S23 Hydro
• Circulation: Single / Dual mode
• Dimensions: 1070 mm (L) × 700 mm (W) × 1390 mm (H)
• Weight: 210 kg
• Coolant: Pure/soft water + antifreeze + corrosion inhibitor
• Max inlet/outlet temperature: 50 / 60 °C
• Cooling type: Dry cooler
• Liquid flow rate: 2 m³/h
• Voltage: 3-phase 380 V / 50 Hz
• Operating temperature range: −25 °C to 45 °C
• Design pressure: 0.3 MPa
• Certification: CE

Features

• Premium water pump
• Stainless steel construction
• EPDM hose connections
• Quick-disconnect couplings
• Heat recovery (Heating variant)
• SHA-256 algorithm compatible
• Quiet operation
